Peb tau tsim peb Cov Plumbing Braided Hose los daws qhov kev mob taub hau: txuas ruaj khov - cov ntsiab lus nyob deb xws li lub hnub ci sau rau nws lub tank lossis lub boiler rau lub tshuab hluav taws xob nyob ze. Peb 2-Meter High-Temperature Resistant PT Braided Hose los ua ntej- ntsuas thiab npaj rau nruab, txuag koj lub sijhawm thiab tsis paub tseeb ntawm kev txiav thiab haum cov kav dej dav dav. Peb xyuas kom meej qhov kub-Resistant 2 m PTFE Cov kav dej xaum xa khoom zoo ib yam li peb cov kev cai ntev, ua rau nws muaj kev xaiv ntse thiab muaj txiaj ntsig rau kev twv ua haujlwm.
Yuav ua li cas peb lav kev ntseeg siab nyob rau hauv ib tug ntev ntev
Txhua Lub Tshuab Hluav Taws Xob Braided Hose peb nkoj yog tsim nrog tib lub hom phiaj ntawm kev ua tau zoo raws li peb tau ua -rau- xaj khoom. Peb siv cov ntawv pov thawj 304 stainless hlau braid thiab PTFE puab liner koj ntseeg. Cov khoom noj khoom haus- qib silicone seals tau ua tib zoo ntsia thiab npaj los tswj cov cua sov caij tsheb tawm ntawm lub thawv. Txhua 2-Meter High-Temperature Resistant PT Braided Hose yog ua ntej- sim, yog li koj tuaj yeem ntseeg tau tias nws yuav ua tau txij hnub ib yam tsis muaj kev hloov kho ntawm qhov chaw.
Qhov Precision Tom qab Peb "Paj-mus-Nruab" Kev cog lus
Peb paub tias "kaw txaus" tsis zoo txaus rau kev teeb tsa ruaj khov. Yog vim li cas peb thiaj tswj tau qhov ntev ntawm peb Cov Cuab Yeej Cuab Yeej-Resistant 2 m PTFE Plumbing Tube. Qhov ntev siv tau yog tsawg kawg yog 1990 hli, nrog kev kam rau siab tsuas yog ± 10 hli. Peb ua ke qhov no nrog tus qauv G1/2 "los yog xaiv G3/4" threads, tag nrho cov precision - tshuab thiab ntsuas - kuaj xyuas qhov xau{13}} dawb foob. Lub braid yog nruj thiab tsis sib xws, nrog rau sab nraud txoj kab uas hla ntawm ± 0.3 hli, ua kom muaj kev sib haum xeeb nrog cov qauv fittings.
Engineered rau kev ua tau zoo, Tsis yog yooj yim xwb
Tsis txhob cia qhov yooj yim dag koj -peb Tsau - Ntev Thermal Hose yog tsim los rau kev ua haujlwm. Nws yog ntsuas rau tib lub siab dua lossis sib npaug rau 1.0 MPa ua haujlwm siab thiab siab dua lossis sib npaug rau 3.0 MPa tawg siab raws li peb cov qauv kab. Nws tiv taus qhov kub ntawm ntau dua lossis sib npaug li 70 degree, ua rau nws zoo tagnrho rau cov dej kub thiab cua sov sib txuas. Qhov ob - crimp kev twb kev txuas yog robust, thiab tag nrho cov sib dhos tau dhau los ntawm peb tus qauv 30-feeb kev sim siab. Rau qhov luv luv (30-60 cm), peb siv tib cov qauv nruj, suav nrog lub dav dav khoov vojvoog rau kev teeb tsa yooj yim hauv qhov chaw nruj.
|
Parameter |
Specification |
|
Yam khoom |
Ua ntej-Txiav Ntev Ntev Hose |
|
Txheem Length |
2 meters (Ntau tshaj lossis sib npaug rau 1990mm, ± 10mm tol.) |
|
Sab hauv |
PTFE (Polytetrafluoroethylene) |
|
Braid Khoom |
304 Stainless hlau |
|
Xov Options |
G1/2", G3/4" (GB/T 7307) |
|
Ua Haujlwm Siab |
Ntau dua lossis sib npaug li 1.0 MPa |
|
Kev kub ntxhov |
Ntau dua lossis sib npaug li 3.0 MPa |
|
Kub Resistance |
Ntau dua lossis sib npaug li 70 degree |
|
Hom kev sib txuas |
Muab ob npaug rau -Crimp Fittings |
